Industrial 5-Port Gigabit Ethernet Switch 10/100/1000TX DIN-Rail Unmanaged

Product Description<br><br>The LS3205T-5GT-LV Industrial 5-Port Gigabit Ethernet Switch is a rugged and reliable networking device built to withstand demanding conditions in factories, warehouses, automation systems, and other industrial settings. It delivers fast, stable wired network connections for your equipment with simple plug-and-play setup.<br><br>Key Features &amp; Benefits:<br><br>Fast &amp; Reliable Networking: Features 5 Gigabit Ethernet ports that automatically adjust speed (10/100/1000 Mbps) for optimal data transfer. Supports jumbo frames for efficient large data handling.<br><br>Built for Tough Environments: Operates flawlessly in extreme temperatures from -40°F to 167°F (-40°C to 75°C). Its sturdy metal housing and fanless design provide excellent durability and protection against dust (IP40 rating).<br><br>Easy Installation &amp; Use: Truly plug-and-play—no configuration needed. Designed for standard DIN-rail mounting (wall-mount optional) for easy integration into control cabinets and industrial panels.<br><br>Industrial-Grade Power &amp; Protection: Supports a wide range of power inputs (DC 12-48V) with built-in protection against overload, reverse polarity, and supports dual redundant power supplies for critical applications.<br><br>Energy Efficient &amp; Quiet: Consumes less than 5W of power and uses silent, passive cooling with no moving parts.<br><br>Peace of Mind: Backed by a 5-year warranty and compliant with major industrial safety and electromagnetic standards (FCC, CE, EN 62368-1).<br><br>Specifications:<br><br>Model: LS3205T-5GT-LV<br><br>Network Ports: 5 x 10/100/1000BASE-T Gigabit Ethernet, Auto-MDI/MDIX<br><br>Switch Performance: 20 Gbps backplane bandwidth, &lt;10 μs latency, Store-and-Forward switching<br><br>Power Supply: DC 12-48V, Redundant input<br><br>Power Consumption: &lt;5W<br><br>Housing &amp; Cooling: Metal case, Fanless<br><br>Protection Rating: IP40<br><br>Installation: DIN-Rail (Standard), Wall-mount (Optional)<br><br>Dimensions (W x H x D): 1.0" x 3.7" x 2.8" (26 x 95 x 70 mm)<br><br>Weight: 2.2 lbs (1 kg) max.<br><br>Operating Temperature: -40°F to 167°F (-40°C to 75°C)<br><br>Certifications &amp; Compliance: FCC, CE-EMC (EN55022 Class A, EN61000-4-2/3/4/5/6), Safety (EN 62368-1), Shock/Vibration (IEC60068-2-27/32/6).<br><br>Ideal for industrial automation, surveillance systems, transportation networks, utility controls, and any application requiring a robust, maintenance-free Ethernet switch.

• • High-Speed, Plug & Play Connectivity: 5 Gigabit Ethernet ports (10/100/1000 Mbps) with auto-negotiation. Simply connect your devices for instant, high-speed networking with no configuration required.
• • Extremely Rugged & Reliable: Built for harsh environments. Features a durable metal case, fanless cooling, and operates reliably in extreme temperatures from -40°C to 75°C (-40°F to 167°F). Rated IP40 for dust protection.
• • Easy Industrial Installation: Designed for standard DIN-rail mounting (wall-mount optional) for quick and secure installation in control panels and industrial cabinets.
• • Industrial-Grade Power Flexibility: Supports a wide DC input range (12~48V) with built-in protection against overload, reverse polarity, and supports dual redundant power supplies for maximum uptime.
• • Energy Efficient & Quiet: Consumes less than 5W of power and uses silent, passive cooling with no moving parts.
