EJYWPSWD Solid State Relay Single Phase Din Rail Mounted Slim Relay with Heat Sink 10a 25a 40a 50a 60a 80a

<p>STEP 1: Choose a correct control Model</p><p>DA: DC Control AC Input:DC3-32V Load:AC24-480V</p><p>AA: AC Control AC Input:AC70-280V Load:AC24-480V</p><p>DD: DC Control DC Input:DC3-32V Load:DC3-75V</p><p>STEP 2: Choose a correct type for current</p><p>For Resistive load: Current of SSR =3 x working current of load</p><p>Resistive load such as Resistance furnace, Incandescent lamp, Oven, Heating rod, Electric water heater.</p><p>For Inductive load: Current of SSR =6 x working current of load</p><p>Inductive load such as Motor,Fan,Transformer,Pump,Air conditioner and other loads with inductives.</p><p>For Capacitive load: Current of SSR =10 x working current of load</p><p>Capacitive load such as Compensating capactitors,Batteries and other loads with capacitors</p><p>1: SSR cannot be tested without load, and must be added load of more than 50W to test.</p><p>2: Use fast fuse(70% Amp of rated SSR) to protect SSR from load short circuit.</p><p>3: Zero-cross Or Random turn-on.</p><p>The default is zero cross SSR.</p><p>Random turn-on needs to be customized.</p><p>Power Source : DC</p><p>Theory : Solid State Relay</p><p>is_customized : Yes</p><p>Contact Load : Low Power</p><p>Model Number : LCDS 10-4048ZD3/LCDS 10-4048ZA2/LCDS 10-4075DD3</p><p>Voltage : 220V</p><p>Use : Protective</p><p>Protect Feature : Sealed</p>
